Four-axis linkage fiber laser welding machine

　　The four-axis linkage fiber welding machine is a high-energy pulsed laser for welding objects. The machine combines laser, laser power supply, control system, cooling system, two-dimensional precision console, Z-axis rotary table, C-axis lifting shaft, operating cabinet, etc., with convenient operation, compact structure and reliable performance.

Advantages of four-axis linkage fiber laser welding machine

　　It is suitable for automatic spot welding, butt welding, lamination welding and sealing welding of various metal materials, and completes the welding of complex plane straight lines, arcs and arbitrary tracks. And it can be customized according to the welding process of the customer's products. The four-axis automatic laser welding machine can complete the work of the previous 4-5 technicians and only need one ordinary worker to complete the operation. The maximum degree is Enterprises save labor costs and improve welding efficiency.

Four-axis linkage fiber laser welding machine application range

　　Used in welding of precision parts such as eyeglass frames, microelectronic components, integrated circuit leads, high power diodes, USB interfaces, power adapters, mobile phone batteries, electronic components, water bottles, vacuum cups, stainless steel products, door handles, molds, etc.

Four-axis linkage fiber laser welding machine parameters

Laser power: 800W

Laser wavelength: 1080nm

Output fiber length: 10M

Laser type: ND: YAG pulse

Spot adjustment range: 0.1mm-0.4mm

Welding depth: 0.1mm-2.5mm

Pulse frequency: 0-50Hz

Spot size: 0.2mm~4.0mm

Observation system: high precision CCD with red light positioning

Machine power consumption: 6KW

Control System: MotionDSP

Power requirements: 380V ± 10% / 60A

Cooling method: 3P water cooling
